Accessories

In very good condition this is a Swift Zernike phase contrast condenser with phase rings for x10, x40 and x100 phase objectives and also a bright field position. Numerical aperture 1.1 and part number 646971

Used only by ourselves for customer demonstrations. The Brunel Digicam Cameras are stand alone streaming cameras that provide a continuous live image to a laptop or PC. The Digicam units work with Windows (from XP to 10). Unlike the Eyecam, these cameras need a cctv adapter to link the camera to standard microscope eyetubes and the cctv adapter can be inserted into the monocular eyetube (23.2mm), or one of the binocular or into the trinocular tube of almost all microscopes. The WiFi units have their own IP address and can send images to any other WiFi enabled unit such as a mobile phone, laptop, PC or iPad etc. These can be used where distance prevents corded connection of the camera to a computer. The WiFi signal reduces the potential resolution and these are available at 1M. Sold with CCTV adapter, USB lead and software.

An eyepiece graticule that will fit standard diameter eyepieces with a graticule shelf. It has a grid of 15 x 15 1mm squares. Condition very good.

This is a wooden microscope case for those microscopists that have to 'marry' their microscopy passion with the furniture of their homes. The back and bottom of these cases are from block MDF but the rest of the case is from 'real wood' - medium oak. Carrying handle and lock and key. This is a substantial case and not really designed for microscope transport but for microscope stowage in full view. External dimensions 480mm height, 400mm depth and 300mm width with internal measurements 430mm height, 350mm depth and 260mm width. A piece of furniture rather than a microscope case.

Used only by ourselves for customer demonstrations. The Brunel Digicam Cameras are stand alone streaming cameras that provide a continuous live image to a laptop or PC. The Digicam units work with Windows (from XP to 10). Unlike the Eyecam, these cameras need a cctv adapter to link the camera to standard microscope eyetubes and the cctv adapter can be inserted into the monocular eyetube (23.2mm), or one of the binocular or into the trinocular tube of almost all microscopes. USB 2.0 Aptina CMOS sensor. Sold with CCTV adapter, USB lead and software - a saving of £68.

As new, automatic or manual modes. sheet size 4 ½ x 4 ½ inches, built in exposure meter with override. suitable for compound and stereomicroscopes.

This is as good as a ring light can get. The Photonic HPRL unit has 8 individual LED lights that can be operated in segments (half, quarter and eighth circle) or as a complete ring with continuous dimming. There is no separate control box and there are both right- and left-hand controls. Autorotation with variable speed is also possible Colour temperature 5800K. Mounting is via a compression ring for objectives with a diameter of 66mm. List price in excess of £800 + vat. Condition excellent.

This Brunel ring light will fit all our zoom stereomicroscopes with the appropriate adapter. It may also fit other makes providing the stereohead has a parallel sided cowling and is less than 65mm in diameter. The unit consists of a fluorescent circular strip light which attaches to the bottom of the stereohead. The ring light is 240v with an on/off switch and provides excellent vertical illumination that is softer than LED lighting. This is a new product used only for our assessment purposes.

In very good condition, this is the Meiji 150 watt fibre optic ring light. The 21 volt 150 watt light source delivers high intensity cold light illumination. Colour temperature at maximum intensity is 3250 degrees Kelvin. The base incorporates an easy release lamp change mechanism and a filter holder. The ring light has a universal adapter which will attach to ant stereomicroscope head that has parallel sides that are suitable for the thumb nut attachment system.

This is a Zeiss Jena drawing attachment that will fit most monocular tube microscopes. The unit fits in place of the eyepiece and produces an image on paper placed next to the microscope that can then be traced round. To be fair this is now almost an antique item but it still works as the makers intended. Complete with original wooden case.

This is a bench clamp hand microtome. It needs specimens to be embedded in paraffin wax or held forcibly between support media such as carrot slices. Sections are cut with a free hand razor

A very compact CCTV camera with BNC and S-video output options. Costar branded. For those who want a TV image from their microscope, this maybe ageing technology but represents a bargain.

A high resolution analogue CCTV camera for TV. BNC and S-video connection. 12v power source supplied together with BNC to AV cables. Unused and still its packaging.

This unit is a fluorescence ring light for a stereomicroscope that produces a 'softer' lighting effect than the current LED ring light alternatives. Simple on/off switch and we have replacement strip lights - if needed.

An LED ring light for stereomicroscopes. This unit has a double ring of LED's with an inner and outer ring that can be used either individually or separately with individual brightness control. Used by ourselves for customer demonstrations. Fully guaranteed

This is not really for the amateur but for those with some experience of microtomy. The microtome was used to cut frozen sections of fixed material by using the sudden expansion of compressed carbon dioxide gas from a cylinder. The connection pipe and freezing stage are present but should only be attached to a cylinder of gas by those who are experienced with the procedure. It currently has a stage that will take paraffin blocks attached to a wooden chuck which can also be sectioned by this microtome. Sectioning knife included. The microtome is clearly well used but is fully functional.

This is a new item recently introduced to our range of lighting. The 78 LED's are arranged in two concentric rings. The control box allows brightness control.. The ring light will fit all the zoom stereomicroscopes in the Brunel range and will fit others providing they have parallel sided turrets up to a maximum of 65mm in diameter.

This is a new and unused condenser for the ML series of the Japanese Meiji compound microscope. Abbe condenser with a numerical aperture of 1.25 with iris diaphragm, Massive discount from list price

This is a condenser unit from Ziess Jena with dovetail fitting. There are three alternate condenser units that will rotate into position, Aplanat (n.a. 1.4), achromat (n.a. 0.3) and a oil darkfield unit. Condition very good.

This is a new addition to our lighting range and has been used only by ourselves for product assessment. The ring light has 78 individual LED's and a polarising filter system that can be rotated to reduce glare from highly reflective surfaces such as metals. This unit will fit all the zoom stereomicroscopes in the Brunel range. It may also fit some other makes providing the stereohead cowling has parallel sides and is less than 65mm in diameter.

A two-part SLR photomicrography attachment that will fit around standard sized eyetubes of compound microscopes (not 30mm diameter). It need camera specific T2 ring (Canon, Nikon, Pentax etc).

The Lumenera cameras are exceptional units that provide crystal clear, vibrant images with high definition (HD), low light CCD, large format, research-grade and pixel shifting technologies. They are one of the most respected digital camera manufacturers in the scientific market, We have this new unit simply because one of our customers were forced to cancel their order. The 2-2C unit has a CCD Sony chip which makes this camera ideal for low light imaging such as fluorescence specimens. Supplied with a CCTV adapter and the Infinity Capture Software. A massive saving on the list price.
